Sim Racing Cockpit Project

My sim racing cockpit project’s almost done (waiting for the prototype) and I’m happy it’s generating hype! For this model I decided to make your lives easier by getting makers and quotations myself and selling the cut parts. For that I need to know your locations to contact local makers and discuss materials & prices.

If you’d like one let me know here.

Specs

Assembled unit dimensions:
1820 x 1180 x 1008 mm (length x width x height)

Adjustment options and ranges:

  • Wheel + shifter + mouse + tower + peripherals + monitor depth – 5 positions – 200 mm range
  • Pedals depth – 6 positions – 300 mm range
  • Wheel height – 4 positions – 160 mm range
  • Shifter + mouse height – 4 positions – 160 mm range
  • Pedals height – 4 positions – 160 mm range
  • Screen height – 4 positions – 160 mm range

Description

A short recap on the dev process:

On July 2021 I tried my cousins sim racing cockpit but I’m very tall, didn’t fit in it and ruined my knees. Moreover, the racing posture was awful cause the Logitech G27 wheel he had was designed to mount on a standard desktop (way lower than your head) and the pedals on the floor, favoring global compatibility instead of faithful racing posture simulation. So I decided to design my own sim racing cockpit to adapt the Logitech kits to a more realistic racing posture and make it adjustable so it fits anyone.

6 months later, my simulator adapts your office chair and Logitech kits to a better racing posture, it is very sturdy, has plenty of wheel, pedals, shifter and monitor adjustment options with over 3000 combinations, has a defined location for the CPU tower and place for your headphones, joysticks and VR headset, and it looks awesome.

This is the latest version:


Wanna read my dev updates with insights, hows, whys, and more specs and schemes? Start here.


Styling Simulator




Your browser does not support the HTML canvas tag.











If you’d like one let me know your location here.

Additional information

Board thickness

18 mm – International, 3/4 in (19 mm) – US

Board size

1220 x 2440 mm | 4 x 8 feet

Boards quantity

1

Desk Width

1200 mm

Estimated milling duration

15 mins

Suitable materials

Hardwood Plywood, MDF, Softwood Plywood

Brand

turnifure.com

License

Attribution-NonCommercial-ShareAlike 4.0 International (CC BY-NC-SA 4.0)
