CNC Plans for Adjustable Shelves Column - Low Console - Material: 19.05mm
Ready to fabricate or customize?
Adjust material thickness, outer dimensions & export vector files
Customize this Plan →
Design Concepts & Renderings
Specifications
| Parameter | Description | Value |
|---|---|---|
| Material Thickness | Thickness of your main material | 19.05 mm |
| Shelves thickness | Thickness of the shelves material | 18 mm |
| Permanent joints fit | Permanent joints tightness. 0 = very tight, 0.2 = looser | 0.1 mm |
| Shelves width margin. | Gap between the shelves width and the cabinet inner width (smaller value = tighter shelves) | 2 mm |
| Min bit diameter | Defines the radius of the fillets and smallest concave curves | 6.1 mm |
| Column Width | The external width of the cabinet | 1200 mm |
| Column Depth | The external depth of the cabinet | 400 mm |
| Column Height | The external height of the cabinet | 700 mm |
| Height regulation gaps | The gap between the holes for the height regulation plugs | 20 mm |
| Quantity of Shelves | Shelves included in the shelves board nesting | 1 mm |
| Material Width | Board width for automatic nesting | 1220 mm |
| Material Height | Board height for automatic nesting | 2440 mm |
Frequently Asked Questions
What material thickness is required for these plans?
These specific CNC plans are parametrically designed for 19.05 mm material. We recommend using high-quality Baltic Birch plywood or MDF that matches this thickness for an exact fit.
What file formats are included?
This parametric plan download generates clean DXF and SVG files, compatible with VCarve, Fusion 360, Shaper Origin, and most other CNC software.
