CNC Plans for Wavy Rack - Low Profile (30 cm) TV Rack and Stand - Material: 18 mm
Ready to fabricate or customize?
Adjust material thickness, outer dimensions & export vector files
Customize this Plan →
Specifications
| Parameter | Description | Value |
|---|---|---|
| Material Thickness | Thickness of your material | 18 mm |
| Permanent joints fit | Permanent joints tightness. 0 = very tight, 0.2 = looser | 0.11 mm |
| Tool bit diameter | Radius of the fillets and smallest concave curves. | 6.46 mm |
| Base height | The height of the base (lowest surface). Default is 160 mm. | 80 mm |
| Level 1 height | The height available for appliances on top of the base shelf. Default is 90 mm. | 100 mm |
| Level 2 height | The height available for appliances on top of the middle shelf. Default is 160 mm. | 100 mm |
| Material Width | Length of Side A of the nesting bin | 1220 mm |
| Material Height | Length of Side B of the nesting bin | 2440 mm |
Frequently Asked Questions
What material thickness is required for these plans?
These specific CNC plans are parametrically designed for 18 mm material. We recommend using high-quality Baltic Birch plywood or MDF that matches this thickness for an exact fit.
What file formats are included?
This parametric plan download generates clean DXF and SVG files, compatible with VCarve, Fusion 360, Shaper Origin, and most other CNC software.
